Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | XFT |
| Certification: | ISO9001 |
| Model Number: | 1060 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1/piece |
| Price: | Negotiated |
| Packaging Details: | Kraft Paper+Wooden Pallet+Wooden Box |
| Delivery Time: | 10-15 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 3000Tons/Month |
|
Detail Information |
|||
| Product Name: | Aluminum Sheet | Material: | 1060 |
|---|---|---|---|
| Thickness: | 3.0mm Above | Type: | Plate |
| Alloy Or No: | Not | Temper: | H14 H24 |
| High Light: | Corrosion Resistance 20mm Aluminium Plate,H24 Plain Aluminium Sheet,H24 20mm Aluminium Plate |
||
Product Description
Wear-resistant 1060 aluminum plate
Product Description
1060 aluminum plate belongs to pure aluminum with a purity of 99.6%. 1060 aluminum plate contains 0.05% copper and has a conductivity of 55%. In addition, the strength of 1060 aluminum plate is relatively low. It is essentially pure aluminum alloy and has many different states, such as O (annealed), H12, H14, H16, H18, etc. In addition, other aluminum plates belonging to the commercial pure forging series can also be used, including 1050, 1070, 1100, etc.
1060 aluminum plate has high plasticity, corrosion resistance, electrical conductivity and thermal conductivity, but its strength is low, it cannot be strengthened by heat treatment, and its machinability is not good; it can be gas welded, hydrogen atom welded, contact welded, and not easy to braze; it is easy to withstand various pressure processing , extend and bend.
Product Display
| Chemical Composition(WT%) | |||||||||
| alloy | (Si) | (Cu) | (Mg) | (Zn) | (Mn) | (Ti) | (V) | (Fe) | (Al) |
| 1060 | ≤0.25 | ≤0.05 | ≤0.03 | ≤0.05 | ≤0.03 | ≤0.03 | ≤0.05 | ≤0.35 | 99.6 |
| Mechanical behavior | |||||||||
| Density | Tensile strength((N/M ㎡) | Other(％) | |||||||
| 2.71 g/cm3 | 110-136 MPa | 3-5% | |||||||
| The difference between aluminum plate 1060 H14 and 1060 H24 | |||||||||
|
H is Hardness
1060 H14 means no heat treatment, only work hardening, so that the tensile strength of the material is between 0 (annealed) and 8 (hard state), which is the average value. 1060 H24 in the H said processing hardening state, H24 said control hardness and other physical properties of the processing process, this is the semi-hard state. |
|||||||||
Application
1060 aluminum sheet is widely used in products which do not require high strength. Products are often used for signs, billboards, building decoration, bus body, high-rise buildings and factory wall decoration, kitchen sinks, lamp holders, fan leaves, electronic parts, chemical instruments, sheet processing parts, deep drawing or spinning concave utensils, welding parts, heat exchangers, clock surfaces and panels, nameplates, kitchenware, decorations, reflective appliances, etc.
